208V Delta - 208 Y 120 (Isolation Transformer)

SKU: MIT-DRY-238
Size:

Size

New

$1,686

Used

$1,349
Quantity:

Estimated Delivery Date: (call to expedite)

Transformer is in stock! Delivers in 5 - 7 business days

Overview

This transformer is designed to convert 3-phase 208v Delta 3-wire to 3-phase 208v Wye 4-wire with a fully rated neutral with a 120v phase-to-neutral voltage to run equipment such as panels, motors, CNC machines, welders, conveyor systems, pumps, printing equipment, fabrication tools, and other business machines. Many customers use this transformer to create a fully isolated 208v circuit from their main circuit.

Not sure what to buy? Find out more about how to buy the right transformer.





Primary Voltage: 208 Delta

Secondary Voltage: 208 Y 120




Transformer Specifications

  • 60 Hz Frequency
  • 150°C Temperature Rise
  • Primary Adjustment Taps 2 above, 4 below in 2.5% increments
  • High Efficiency Aluminum Windings
  • 220°C Insulation Class
  • Vacuum pressure Impregnated Windings
  • High Efficiency Design
  • Silicon Steel Core
  • Lugs included up to 75 kVA





Size Guide

kVA Amps at 208v Amps at 480 Y 277
15 42 18
30 83 36
45 125 54
75 208 90
112.5 312 135
150 416 180
225 625 271
300 833 361
500 1388 601



Dimensions & Weights

kVA Dimensions (HxWxD) Weight (lbs)
15 28"x21"x14" 220
30 32"x27"x17" 320
45 32"x27"x17" 385
75 39"x29"x20" 565
112.5 41"x32"x22" 725
150 41"x32"x22" 860
225 52"x41"x25" 1465
300 52"x41"x36" 1600
500 66"x51"x41" 2900



Approximate Enclosure Dimensions & Weights


Shipping rates vary, but are generally 10% of the total purchase price.

Transformers deliver in 5-7 business days.

Read more here: Shipping Policy

Ordered the wrong unit, or not sure if a product is right for you? Our web store exchange policy has you covered! We’ll send you a replacement transformer, all you pay for is shipping, plus the difference in unit price. Our policy lasts 30 days. If 30 days have gone by since your purchase, we cannot offer you a refund or exchange, but we still may be interested in buying the unit back. Proof of purchase is required to process a return or exchange.

Read more here: Return and Refund Policy

Buy with confidence. All new and used Maddox transformers are tested and come with a full 5 year warranty against defects. If you experience any problems just give us a call and receive a replacement, free of charge. We'll even pay the shipping!

Read more here: Warranty, Terms and Conditions
